This conveyor is in great working condition.
It's made out of stainless steel with a vinyl belt with plenty of cleats.
Motor Power: 0.55kW 415V 3 Phase
MEASUREMENTS
Travel: 2800mm
Belt Width: 460mm
Cleat Height: 50mm
Discharge Height: 2250mm
Overall Dimensions (mm): 3450 x 800 x 2930 h

STAINLESS STEEL ELEVATOR INCLINE CONVEYOR 2.25M HIGH

Make us an offer! We're highly negotiable and take all reasonable offers seriously.
Heavy duty inclined conveyor designed for reliable product elevation in continuous industrial environments. Fitted with a chevron cleated belt to ensure positive grip and controlled transfer, even with bulk or irregular materials etc. Built for robust throughput where stability and consistent feed are essential. Ideal for feeding hoppers, transferring product to higher levels, and integrating into automated lines.
Features:
- Chevron cleated belt for increased traction and product retention on incline
- Heavy duty frame and construction for demanding production settings
Belt Travel (mm): 4000
Belt Width (mm): 450
Conveyor Height - Peak (mm): 2800
Conveyor Height - Lowest (mm): 200
Side Guards (mm): 300 High approx.
Power: 415V 3 Phase
Motor Power: 1.1kW
Motor Speeds: 1400 RPM
Overall Dimensions (mm): 4380 L x 1000 W x 3100 H
Make us an offer! We're highly negotiable and take all reasonable offers seriously.

HEAVY DUTY ELEVATOR INCLINE CONVEYOR 2.8M HIGH

Large incline belt conveyor in great condition. Suitable for transferring bulk materials between different heights. Mounted on a freestanding steel frame with castor wheels for mobility and flexible positioning within a plant environment.
Features:
- Integrated feed hopper
- Mounted on castor wheels for mobility
- Simple, robust construction for industrial use
Travel (mm): 4200
Belt Width (mm): 280
Belt Height - Highest (mm): 3000
Belt Height - Lowest (mm): 720
Side Railing/Guards (mm): 200 High
Feed Hopper Height (mm): 635 high
Cleat Height (mm): 15
Distance between Cleat sets (mm): 1000mm
Rated Voltage: 415V 3 Phase
Motor Power: 0.75 kW
Motor Speed: 1380 RPM
Overall Dimensions (mm): 4500 L x 780 W x 3100 H

HEAVY DUTY MOTORISED ELEVATOR INCLINE CONVEYOR 3M HIGH

In great working condition.
Belt Width: 260mm
Cleat Height: 75mm
Outlet Height: 2570mm

TALL Z-TYPE ELEVATOR INCLINE CONVEYOR 2.5M HIGH

This conveyor is in great working condition.
The hopper part is made out of stainless steel.
Voltage: 440-480V
Motor Power: 0.37kW
Belt Width (mm): 550
Discharge Height (mm): 1025
Overall Dimensions (mm): 1500 L x 1115W x 1100 H

STAINLESS STEEL ELEVATOR INCLINE CONVEYOR - 1.1M HIGH STAINLESS STEEL ELEVATOR INCLINE CONVEYOR

This elevator incline conveyor is in great working condition.
The legs are capable of manual adjustable height, and the conveyor's incline can be manually adjusted as well. This unit also comes equipped with wheels and brakes for easy mobility and simple button controls for operation.
Make: Shini Plastics Technology
Model: CB-3
Year: 2009
Voltage: 230V Single Phase
Motor Power: 0.25kW
Belt Width (mm): 450
Belt Travel - Lower Run (mm): 500
Belt Travel - Incline Run (mm): 1350
Belt Travel - Total (mm): 1850
Belt Height - Lower End (mm): 360
Belt Height - Higher End (mm): 1040
Belt Cleats Height (mm): 20
Belt Segments (mm): 490 L x 450 W
Overall Dimensions (mm): 1900 L x 770 W x 1235 H

SHINI CB-3 MOTORISED ELEVATOR INCLINE CONVEYOR - 1M HIGH

Inclined belt conveyor, from Genox, suitable for continuous transfer of bulk material between process stages. This unit features a cleated belt design to assist with material carry on inclines and is fitted with side guides for controlled conveying. Built on a heavy duty steel frame with adjustable support legs and castors, it is well suited to recycling, waste handling, or general industrial material transfer applications.
Make: Genox
Model: CBP5040L
Year: 2017
Belt Travel (mm): 4890
Belt Width (mm): 330
Conveyor Height - Peak (mm): 2050
Conveyor Height - Lowest (mm): 345
Side Guards Height (mm): 150
Cleats (mm): 300 W x 40 H
Distance between Cleat sets (mm): 415
Power: 415V 3 Phase
Motor Power: 1.5kW
Motor Speeds: 1400 RPM
Overall Dimensions (mm): 4900 L x 1160 W x 2250 H

GENOX CBP5040L INDUSTRIAL MOTORISED ELEVATOR INCLINE BELT CONVEYOR - 2M HIGH

This conveyor is in great working condition.
It has a orienting roller sorter at the discharge end for feeding certain products at a consistent position.
Hopper Volume: approx 150L
Belt Width: 240mm
Discharge Height from Sorter: 1650mm

HOPPER ELEVATOR CONVEYOR WITH ROLLER SORTER

This conveyor is in great condition. It features a PVC sidewall to help with keeping product
Note: The unit doesn't come with legs.
Belt Length (mm): 4300
Belt Width (mm): 400
Cleat Width (mm): 400
Cleat Height (mm): 70
Distance between Cleats (mm): 250
Voltage: 4515V 3 Phase
Motor Power: 0.75 kW
Motor Speed: 1400 RPM
Overall Dimensions - As in photos (mm): 5000 L x 730 W x 700 H

MOTORISED ELEVATOR INCLINE CONVEYOR 4.3M LONG BELT

Inclined belt conveyor in excellent condition designed as a straightforward and practical conveyor for general material conveying where elevation change is required. Fitted with a durable textured rubber belt for grip and continuous operation. This unit is mounted on castors for easy repositioning.
Travel (mm): 6700
Width (mm): 1000
Belt Height - Peak (mm): 2300
Belt Height - Lowest (mm): 780
Voltage: 415V 3 Phase
Motor Power: 0.37kW
Motor Speed: 1370 RPM
Overall Dimensions (mm): 7000 L x 1350 W x 2300 H

LARGE HEAVY DUTY MOTORISED INCLINE ELEVATOR CONVEYOR 2.3M HIGH

This conveyor is in great condition. Designed to move materials or products at an upward angle, bridging differences in elevation. Commonly used in various industries.
Belt Travel (mm): 3100
Belt Width (mm): 600
Cleat Height (mm): 40
Cleat Width (mm): 380
Distance between each Cleat (mm): 400
Power: 415V 3 Phase
Motor Power: 0.37kW
Motor Speeds: 1380 RPM
Overall Dimensions (as seen in photos) (mm): 3200 L x 950 W x 470 H

STAINLESS STEEL ELEVATOR INCLINE CONVEYOR 3.1M LONG

This conveyor is in great condition. Designed to move materials or products at an upward angle, bridging differences in elevation. They are commonly used in various industries.
Belt Travel (mm): 3900
Belt Width (mm): 600
Cleat Height (mm): 50
Cleat Width (mm): 540
Distance between each Cleat (mm): 200
Overall Dimensions (as seen in photos) (mm): 4000 L x 1105 W x 710 H

STAINLESS STEEL ELEVATOR INCLINE CONVEYOR 3.9M LONG
